CNC (Computer Numerical Control) machines and VMCs (Vertical Machining Centers) often generate a significant amount of chips or swarf during the machining process. Chip conveyors are essential components in these machines to efficiently remove the chips and maintain a clean working environment. Here’s how chip conveyors are typically utilized in CNC and VMC machines:

1. Hinged Belt Conveyors: Hinged belt conveyors are commonly used in CNC and VMC machines due to their effectiveness in handling various types of chips, including metal and plastic. These conveyors feature a series of interlocking hinged steel belts that form a continuous moving surface to carry chips away from the machining area. They are versatile and can handle a wide range of chip sizes and shapes.

2. Integration with Machine Design: Chip conveyors are often integrated into the design of CNC and VMC machines, either as a built-in feature or as an optional add-on. They are typically located below the machining area to collect chips as they are generated during the machining process.

3. Automatic Chip Removal: Chip conveyors in CNC and VMC machines are designed for automatic chip removal, continuously transporting chips away from the machining area to a designated collection point or disposal area. This automated process helps maintain a clean and clutter-free workspace, reducing the risk of chip buildup that can interfere with machining operations.

4. Customization for Machine Size and Configuration: Chip conveyors can be customized to suit the size and configuration of CNC and VMC machines. They are available in various lengths, widths, and configurations to accommodate different machine sizes and layouts. Additionally, chip conveyors can be integrated with coolant systems to enhance chip removal and coolant management capabilities.

5. Maintenance and Cleaning: Proper maintenance and cleaning of chip conveyors are essential to ensure their reliable operation. Regular inspection, cleaning, and lubrication of conveyor components help prevent issues such as jamming, belt wear, and chip buildup. Some chip conveyors feature automatic cleaning systems to remove debris and maintain optimal performance.

6. Environmental Considerations: Proper disposal of collected chips is important to minimize environmental impact and comply with regulations. Depending on local regulations and recycling opportunities, chips may be recycled, reused, or disposed of in an environmentally responsible manner.

Overall, chip conveyors are crucial components of CNC and VMC machines, facilitating efficient chip removal and maintaining a clean working environment. They help optimize machining efficiency, extend tool life, and ensure the quality of machined parts.
